2022 EDITION General Catalogue Solenoid Valves for Fluid Control

2 WARNING - USER RESPONSIBILITY FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE. • This document and other information from Parker-Hannifin Corporation, its subsidiaries and authorized distributors provide product or system options for further investigation by users having technical expertise. • The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met. The user must analyze all aspects of the application, follow applicable industry standards, and follow the information concerning the product in the current product catalog and in any other materials provided from Parker or its subsidiaries or authorized distributors. • To the extent that Parker or its subsidiaries or authorized distributors provide component or system options based upon data or specifications provided by the user, the user is responsible for determining that such data and specifications are suitable and sufficient for all applications and reasonably foreseeable uses of the components or systems. Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Who we are? The Fluid Control Solutions Europe (FCSE) Business Unit is part of the Fluid and Climate Controls Division Europe (FCCE) of Parker Hannifin, the global leader in Motion and Control Technologies. FCSE core competences are the development and manufacturing of an extremely diverse range of fluid control products, including solenoid valves and pressure regulators. Where we are? Our European headquarters are located in Gessate (Milan-Italy) , this is also where our R&D, Marketing, Application Support and Product Management functions are located. Our Products are mainly manufactured in Gessate (Milan - Italy). The Parker Sales Companies and comprehensive distribution network support you, wherever you are. History Parker FCSE has been a leading player in the manufacturing and development of solenoid valve technologies for over 60 years, with continuous research and development bringing innovative solutions to the marketplace, for example leading the way in the utilisation of synthetic ruby for critical waterapplicationsortheunsurpassedreliabilityand precision of our pressure regulators. The expertise accumulated and developed through the years is evident in the superior quality of FCSE solutions. Markets Our products and solutions are typically designed for markets including Industrial Equipment, Industrial Automation, Mobile, Transportation, Life Sciences, Beverage dispensing and for Fluid and Process Control. Benefits The modular concept of our products, having separate solenoid valves and electrical parts, provides the customer with increased flexibility by allowing numerous combinations. This additional flexibility can enable distributors to greater reduce valve inventory levels, whilst retaining the same number of capabilities. Parker also has unrivalled experience in developing customised product solutions complying with the highest technical, environmental, energy and service life requirements.

3 ORGANIZATION OVERVIEW Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 FCSE HEADQUARTER - GESSATE (MI) - ITALY

4 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 GENERAL CATALOGUE FCSE TABLE OF CONTENT INTRODUCTION A complete range of solenoid valves. ......................................................................................................................................06 A modular concept........................................................................................................................................................................08 ATEX Certification. .........................................................................................................................................................................10 World class standards. ................................................................................................................................................................. 11 How to use this catalogue. ..........................................................................................................................................................12 How to select a valve.....................................................................................................................................................................14 How to order....................................................................................................................................................................................16 How to use coil groups.................................................................................................................................................................18 2 WAY VALVES Valves for dry or lubricated air, neutral gases and liquids. ................................................................................................21 Valves for water and neutral liquids..........................................................................................................................................61 Anti water hammer valves. ..........................................................................................................................................................89 Hot water and steam valves......................................................................................................................................................101 Valves for hydraulic oil and neutral liquids (up to 100 bar)......................................................................................................111 High corrosion resistant valves (303 Stainless Steel)................................................................................................................127 High corrosion resistant valves (316L Stainless Steel)...............................................................................................................143 Oil burner valves...........................................................................................................................................................................155 Fast switching valves...................................................................................................................................................................167 3 WAY VALVES Valves for dry or lubricated air, neutral gases and liquids. ..............................................................................................171 Valves for hydraulic oil and neutral liquids (up to 75 bar)...................................................................................................... 209 High corrosion resistant valves (303 Stainless Steel)................................................................................................................213 Valves for beverage dispensing - Liquipure®.......................................................................................................................219 2 & 3 WAY VALVES FOR TRANSPORTATION 2 way............................................................................................................................................................................................... 233 3 way............................................................................................................................................................................................... 239

5 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 5 WAY DISTRIBUTORS FOR PNEUMATIC APPLICATIONS 5 way pneumatic distributors (Pipe mounting/Sub-base mounting)......................................................................................... 243 3 & 5 WAY PNEUMATIC DISTRIBUTORS FOR ACTUATION CONTROL 3 & 5 way pneumatic valves for actuator control (Pipe mounting)..................................................................................... 269 3 & 5 way pneumatic valves for actuator control (NAMUR). ...............................................................................................301 316L Stainless Steel 3 & 5 way valves for actuator control (Pipe mounting and NAMUR)................................................ 343 ELECTROPNEUMATIC PRESSURE REGULATORS EPP4 Series - Basic, Comfort , Comfort ATEX Ranges. ..................................................................................................379 COILS, HOUSINGS & ELECTRICAL PARTS Introduction.................................................................................................................................................................................... 411 Coils. ................................................................................................................................................................................................ 413 Explosion Proof Electrical Parts.............................................................................................................................................. 443 Housings.........................................................................................................................................................................................473 Coil Accessories...........................................................................................................................................................................478 Explosive Environments............................................................................................................................................................ 480 Guidance Chart for IS-Barriers............................................................................................................................................... 490 TECHNICAL INFORMATION ABOUT SOLENOID VALVES Technical information about solenoid valves...................................................................................................................... 492 APPENDIX Table of sub-bases for valves...................................................................................................................................................513 Table of voltage codes for coils and electrical parts. ........................................................................................................514 Index by Coil Reference.............................................................................................................................................................518 Index by Coil Group.................................................................................................................................................................... 520 Index by Valve reference........................................................................................................................................................... 522 Index for Valves............................................................................................................................................................................ 524

6 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 2 & 3 WAY VALVES FOR TRANSPORTATION • 2 way- direct and piloted • 3 way- direct operated 3&5 WAY DISTRIBUTORS FOR PNEUMATIC APPLICATIONS • Pipe mounted/ Sub-base mounting A COMPLETE RANGE OF SOLENOID VALVES FOR FLUID CONTROL 2 WAY VALVES • For dry or lubricated air, neutral gases and liquids • For water and neutral liquids • Anti water hammer • Hot water and steam • For hydraulic oil and neutral liquids (Max. 100 bar) • High corrosion resistant (303 Stainless Steel) (316L Stainless Steel) • Oil burner • Fast switching • Liquipure® for beverage dispensing 3 WAY VALVES • For dry or lubricated air • For hydraulic oil and neutral liquids (Max. 75 bar) • High corrosion resistant (303 Stainless Steel) • Liquipure® for beverage dispensing

7 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 COILS & ELECTRICAL PARTS • Coils • Housings • Explosion-Proof Electrical Parts 3 & 5 WAY PNEUMATIC DISTRIBUTORS FOR ACTUATION CONTROL • Pipe mounted • NAMUR interface • 316L Stainless Steel (Pipe mounted and with NAMUR interface) EPP4 SERIES ELECTROPNEUMATIC PRESSURE REGULATORS • Basic • Comfort • Comfort ATEX

8 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Actuation Modes • Direct Operated • Manual Reset • Magnalift • Externally Operated • Pilot Operated Internal Design • Piston • Diaphragm • Poppet • Spool Control Functions • Normally Closed • Control by Electric • Normally Open Impulse • Universal • Dual Solenoids • PWM Mounting Solutions • Pipe • Banjo • Sub-base • CETOP • NAMUR • ISO Material Types • Brass • Anodized Aluminium • 303 Stainless St. • Zinc Alloy • 316L Stainless St. • POM A MODULAR CONCEPT FOR EVERY APPLICATION CHOOSE BETWEEN: Seals • FKM • Ruby • NBR • PUR • EPDM • PCTFE…

9 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022

10 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 ATEX CERTIFICATION ELECTRICAL PART ATEX CERTIFICATION A selection of electrical parts conform to the terms of the 2014/34/EU directive and are made for potentially explosive environments - zone 0/20, 1/21 and 2/22. Within the coil section, the presence of the ATEX logo shows that the coil is ATEX approved. PRESSURE VESSELS ATEX CERTIFICATION A selection of pressure vessels conform to the terms of the 2014/34/EU directive specific to non electrical equipment for use within potentially explosive environments - zones 0/20, 1/21 and 2/22. NAMUR & piped valve ranges now include a marking which indicates mechanical ATEX approval. Within the valve section, the presence of the ATEX logo shows that the valve is ATEX approved. SOLENOID VALVE CERTIFICATION When both the electrical and mechanical part are ATEX approved, the solenoid valve can be used in explosive atmospheres. The solenoid valve can be delivered assembled and tested.

11 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 FCSE IS MEETING WORLD CLASS STANDARDS QUALITY STANDARDS: • ISO 9001 • ISO 14001 • OHSAS 18001 • ISO 45001 : 2018 CERTIFICATIONS AND APPROVALS: Our products have been approved and are compliant with the relevant market requirements including: • CE • ATEX • RoHS • UL • REACH • IECEx • CSA • DIN-TUV • AGA • NEPSI • KOSHA • IMQ • NSF • VDE • Ex EAC • UKCA

12 27 Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 Actuation Body Function Port Size Orifi ce (mm) Flow Factor Kv(l/min) MOPD (bar) Max Fluid Temp. (°C) Page Parker Valves Page Parker LUCIFER® Valves Direct Operated Brass/Pipe mounting Normally Closed 1/8'' 1.2 to 3 4.5 70 140 28 32 1/4'' 1.2 to 5 13 100 140 30 32 3/8'' 4 to 6 12 10 120 - 36 1/2'' 8.5 to 11 36 4 120 - 36 Normally Open 1/8'' 2.5 3.5 30 140 - 40 1/4'' 1.5 to 3 4 40 140 38 40 Control by Electric Impulse 1/4'' 3 to 5 11 20 100 - 40 Brass/Sub-base mounting Normally Closed 5 mm 1.5 to 3 4.5 100 130 - 42 Normally Open 5 mm 1.5 1.5 20 120 - 44 Magnalift Brass/Pipe mounting Normally Closed 3/8'' 13 to 15 65 20 140 46 48 1/2'' 13 to 15 65 20 140 46 48 3/4'' 15 to 20 100 20 140 46 50 1'' 15 to 25 170 20 140 46 52 Pilot Operated Brass/Pipe mounting Normally Closed 1/4'' 8 to 12 36 40 120 - 56 3/8'' 11 to 13 50 40 120 54 58 1/2'' 11 to 15 60 40 120 54 60 3/4'' 15 to 20 135 40 120 54 62 1'' 18 to 28 270 16 120 54 64 1 1/2'' 40 425 16 120 - 66 2'' 40 540 16 120 - 66 Normally Open 1/4'' 8 36 40 140 - 70 3/8'' 11 to 13 50 40 140 68 70 1/2'' 13 to 15 60 40 140 68 70 3/4'' 15 to 20 135 40 120 68 72 1'' 25 to 40 420 16 120 68 72 1 1/4'' 28 270 16 120 - 72 1 1/2'' 40 420 12 100 - 72 2'' 40 540 12 120 - 72 Control by Electric Impulse 1/4'' 12 32 12 100 - 74 3/8'' 12 45 12 100 - 74 1/2'' 12 50 12 100 - 74 3/4'' 18 100 12 100 - 74 1'' 18 110 12 100 - 74 Brass/Sub-base mounting Normally Closed 14 mm 14 45 40 140 - 76 Normally Open 14 mm 14 46 40 120 - 76 2 WAY VALVES VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 Oil Water Air Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 This catalogue is a comprehensive list of Parker Solenoid Valves program. It will help to identify appropriate valves and coils and enable the user to generate ordering numbers. This catalogue is split product range. You will find a summary page at the beginning of each valve section. For ease of use, each valve section is divided by application. On the first page of each Application section, you will find an overview of the products within and their technical characteristics, to guide you to the relevant page (example below): SECTION SUMMARY PAGE For further technical information regarding Actuation, Body and Function, please refer to the technical information section at the end of the catalogue. Application Number of ways / positions Related page Technical features Applicable Fluids Function Actuation, body and function Body Mounting Actuation Product range HOW TO USE THIS CATALOGUE

13 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 SECTION PRODUCT PAGE Applicable Approvals within this page Quick selection table with Min/Max values for all valves on the page Dimensional 2D* and 3D drawings A choice of Coil Groups compatible with the selected valve. ISO 1219 Symbol * 2D drawing shown always corresponds to the standard coil. Ordering information

14 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Once you are in the selected range ➊ and application ➋The table is designed to help you navigate to the products matching your criteria. First decide the actuation ➌, then move accross the table selecting your body material ➍, function ➎ and technical requirements ➏. After you have found products fitting within your specification, please go to the corresponding page number in the final column ➐, here you will find a selection of products that match your criteria. ➊ SELECT PRODUCT FAMILY ➐ SELECT CORRESPONDING PAGE ➏ SELECT TECHNICAL DATA ➎ SELECT FUNCTION ➍ SELECT BODY ➌ SELECT ACTUATION ➋ SELECT APPLICATION HOW TO SELECT A VALVE

15 27 Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 Actuation Body Function Port Size Orifi ce (mm) Flow Factor Kv(l/min) MOPD (bar) Max Fluid Temp. (°C) Page Parker Valves Page Parker LUCIFER® Valves Direct Operated Brass/Pipe mounting Normally Closed 1/8'' 1.2 to 3 4.5 70 140 28 32 1/4'' 1.2 to 5 13 100 140 30 32 3/8'' 4 to 6 12 10 120 - 36 1/2'' 8.5 to 11 36 4 120 - 36 Normally Open 1/8'' 2.5 3.5 30 140 - 40 1/4'' 1.5 to 3 4 40 140 38 40 Control by Electric Impulse 1/4'' 3 to 5 11 20 100 - 40 Brass/Sub-base mounting Normally Closed 5 mm 1.5 to 3 4.5 100 130 - 42 Normally Open 5 mm 1.5 1.5 20 120 - 44 Magnalift Brass/Pipe mounting Normally Closed 3/8'' 13 to 15 65 20 140 46 48 1/2'' 13 to 15 65 20 140 46 48 3/4'' 15 to 20 100 20 140 46 50 1'' 15 to 25 170 20 140 46 52 Pilot Operated Brass/Pipe mounting Normally Closed 1/4'' 8 to 12 36 40 120 - 56 3/8'' 11 to 13 50 40 120 54 58 1/2'' 11 to 15 60 40 120 54 60 3/4'' 15 to 20 135 40 120 54 62 1'' 18 to 28 270 16 120 54 64 1 1/2'' 40 425 16 120 - 66 2'' 40 540 16 120 - 66 Normally Open 1/4'' 8 36 40 140 - 70 3/8'' 11 to 13 50 40 140 68 70 1/2'' 13 to 15 60 40 140 68 70 3/4'' 15 to 20 135 40 120 68 72 1'' 25 to 40 420 16 120 68 72 1 1/4'' 28 270 16 120 - 72 1 1/2'' 40 420 12 100 - 72 2'' 40 540 12 120 - 72 Control by Electric Impulse 1/4'' 12 32 12 100 - 74 3/8'' 12 45 12 100 - 74 1/2'' 12 50 12 100 - 74 3/4'' 18 100 12 100 - 74 1'' 18 110 12 100 - 74 Brass/Sub-base mounting Normally Closed 14 mm 14 45 40 140 - 76 Normally Open 14 mm 14 46 40 120 - 76 2 WAY VALVES VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 Oil Water Air Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022

16 36 Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 BRASS NORMALLY CLOSED PIPE MOUNTING Port size Orifi ce Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Parker LUCIFER® Valves Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 3/8'' 4 7.5 0.45 480 0 10 4 -10 100 FKM 121K3206 2995 481865 8 9 2.0 3551 4 7.5 0.45 480 0 10 5 -10 120 FKM 121K3206 4270 481000 8 8 2.0 3551 4 7.5 0.45 480 0 10 10 -10 120 FKM 121K3206 4270 486265 14 14 2.0 3551 5 11 0.66 750 0 7 2 -10 100 FKM 121K3106 2995 481865 8 9 2.0 3551 5 11 0.66 750 0 7 2.8 -10 120 FKM 121K3106 4270 481000 8 8 2.0 3551 5 11 0.66 750 0 7 5 -10 120 FKM 121K3106 4270 486265 14 14 2.0 3551 6 12 0.72 1100 0 5 1.1 -10 100 FKM 121K3306 2995 481865 8 9 2.0/14.2 3551 6 12 0.72 1100 0 5 1.5 -10 120 FKM 121K3306 4270 481000 8 8 2.0/14.2 3551 6 12 0.72 1100 0 5 3 -10 120 FKM 121K3306 4270 486265 14 14 2.0/14.2 3551 1/2'' 8.5 25 1.5 1600 0 1.1 0.5 -10 100 FKM E121K46 2995 481865 8 9 2.0 3427 8.5 25 1.5 1600 0 2.2 0.5 -10 120 FKM E121K46 4270 481000 8 8 2.0 3427 8.5 25 1.5 1600 0 4 1.2 -10 120 FKM E121K46 4270 486265 14 14 2.0 3427 11 36 2.16 2500 0 0.7 0.3 -10 100 FKM E121K45 2995 481865 8 9 2.0 3427 11 36 2.16 2500 0 1.2 0.35 -10 120 FKM E121K45 4270 481000 8 8 2.0 3427 11 36 2.16 2500 0 2.5 0.7 -10 120 FKM E121K45 4270 486265 14 14 2.0 3427 Notes: 1. Valve compatible with water only up to 40°C 2. With manual override 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 HOW TO ORDER PARKER SOLENOID VALVES A SOLENOID VALVE IS COMPOSED OF 3 ELEMENTS: The Valve ➊ + Housing ➋ + Coil ➌ 1. Choose the valve reference 2. Choose the housing 3. Choose the coil ➋ Select the housing depending on the protection level (IP 44 to IP 67 found in the coil section) ➊ Choose the Valve Reference

17 446 COILS COILS FOR DIN PLUG CONNECTION COILS 32 mm Specification Standard Double frequency Ref. (without DIN plug) Ref. (with DIN plug) 481865 482725 483510 482635 Coil Group 2.0 / 2.1 Degree of protection IP65 according to IEC / EN 60529 standards (with DIN plug). Class of insulation F 155°C Electrical connection The coil is connected with a 2 P + E plug according to EN 175301-803 type A Ambient temperature -40°C to +50°C The application is limited also by the temperature range of the valve. Elect. Power DC Pn (hot) 9 W - P (cold) 20°C 12 W - AC Pn (holding) 8 W 9 W Attraction cold 26 VA (9 W) 32 VA (10 W) Weight 130 g (without plug) Voltages "Un" VAC/Hz Code VDC Code VAC/Hz Code -10% to +10% of the Un 24/50 48/50 110/50 220-230/50 A2 A4 A5 3D 24 48 110 C2 C4 C5 24/50, 24/60 48/50, 48/60 110-115/50, 120/60 220-240/50, 240/60 PO S4 S5 S6 These coils can be mounted with every Parker solenoid valves corresponding to the specified Coil Group. See column "Coil Group" within valve pages. This is an encapsulated assembly comprising a coil, integral magnetic iron path and snap-on plug connection. The synthetic material encapsulation provides an effective compact housing, offering full protection against dust, oil, water, etc. Ease of mounting in confined space - offers shock and corrosion protection - simplifies conversion of existing equipment to other requirements, etc. Coils conform to the IEC/CENELEC safety standards and complies with European low-voltage directive. To Order a Coil choose Coil Ref + Voltage Code, example: 481865 for 24 VDC = 481865C2 More voltage possibilities can be found in the table of voltage codes at the end of the coil section. These coils must be used with suitable housings, see example below: The coil assembly kit Ref. 2995 corresponds to the "housing" of Lucifer® valve numbering system (Valve - housing - coil/voltage). It is composed of a nameplate giving details of the valve type, a round washer and a nut to ensure the fixing between 32 mm coil and the valve. 2.0/2.1 COIL GROUP Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 Coil Ref. Voltage Code Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 IMPORTANT: Valve, Housing or Coil shall be ordered separately. In case you would require configured products, please consult your Parker contact or the PH Connect to determine available configurations. Parker coils are available in many different voltages. Choose the one you need by putting the voltage code at the end of your ordering number. ➌ Choose the coil and voltage code Valve and coil order example: ➊ ➋ ➌ 121K3206 2995 481865A2 Valve Housing Coil and Reference Voltage Code

18 36 Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 BRASS NORMALLY CLOSED PIPE MOUNTING Port size Orifi ce Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Parker LUCIFER® Valves Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 3/8'' 4 7.5 0.45 480 0 10 4 -10 100 FKM 121K3206 2995 481865 8 9 2.0 3551 4 7.5 0.45 480 0 10 5 -10 120 FKM 121K3206 4270 481000 8 8 2.0 3551 4 7.5 0.45 480 0 10 10 -10 120 FKM 121K3206 4270 486265 14 14 2.0 3551 5 11 0.66 750 0 7 2 -10 100 FKM 121K3106 2995 481865 8 9 2.0 3551 5 11 0.66 750 0 7 2.8 -10 120 FKM 121K3106 4270 481000 8 8 2.0 3551 5 11 0.66 750 0 7 5 -10 120 FKM 121K3106 4270 486265 14 14 2.0 3551 6 12 0.72 1100 0 5 1.1 -10 100 FKM 121K3306 2995 481865 8 9 2.0/14.2 3551 6 12 0.72 1100 0 5 1.5 -10 120 FKM 121K3306 4270 481000 8 8 2.0/14.2 3551 6 12 0.72 1100 0 5 3 -10 120 FKM 121K3306 4270 486265 14 14 2.0/14.2 3551 1/2'' 8.5 25 1.5 1600 0 1.1 0.5 -10 100 FKM E121K46 2995 481865 8 9 2.0 3427 8.5 25 1.5 1600 0 2.2 0.5 -10 120 FKM E121K46 4270 481000 8 8 2.0 3427 8.5 25 1.5 1600 0 4 1.2 -10 120 FKM E121K46 4270 486265 14 14 2.0 3427 11 36 2.16 2500 0 0.7 0.3 -10 100 FKM E121K45 2995 481865 8 9 2.0 3427 11 36 2.16 2500 0 1.2 0.35 -10 120 FKM E121K45 4270 481000 8 8 2.0 3427 11 36 2.16 2500 0 2.5 0.7 -10 120 FKM E121K45 4270 486265 14 14 2.0 3427 Notes: 1. Valve compatible with water only up to 40°C 2. With manual override 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 It is also possible to choose the coil first and then select the valve using coil groups. HOW TO USE COIL GROUPS One of Parker's strengths is the modularity, adaptability and flexibility of our products. When you select a solenoid valve, the coils displayed in the table have been chosen as they will fulfill the majority of application requirements. However, in some specific cases, you will need special features that will lead you to choose another coil. Groups have been created in order to facilitate the selection of a compatible coil with the chosen valve. WITHIN A VALVE PAGE

19 446 COILS COILS FOR DIN PLUG CONNECTION COILS 32 mm Specification Standard Double frequency Ref. (without DIN plug) Ref. (with DIN plug) 481865 482725 483510 482635 Coil Group 2.0 / 2.1 Degree of protection IP65 according to IEC / EN 60529 standards (with DIN plug). Class of insulation F 155°C Electrical connection The coil is connected with a 2 P + E plug according to EN 175301-803 type A Ambient temperature -40°C to +50°C The application is limited also by the temperature range of the valve. Elect. Power DC Pn (hot) 9 W - P (cold) 20°C 12 W - AC Pn (holding) 8 W 9 W Attraction cold 26 VA (9 W) 32 VA (10 W) Weight 130 g (without plug) Voltages "Un" VAC/Hz Code VDC Code VAC/Hz Code -10% to +10% of the Un 24/50 48/50 110/50 220-230/50 A2 A4 A5 3D 24 48 110 C2 C4 C5 24/50, 24/60 48/50, 48/60 110-115/50, 120/60 220-240/50, 240/60 PO S4 S5 S6 These coils can be mounted with every Parker solenoid valves corresponding to the specified Coil Group. See column "Coil Group" within valve pages. This is an encapsulated assembly comprising a coil, integral magnetic iron path and snap-on plug connection. The synthetic material encapsulation provides an effective compact housing, offering full protection against dust, oil, water, etc. Ease of mounting in confined space - offers shock and corrosion protection - simplifies conversion of existing equipment to other requirements, etc. Coils conform to the IEC/CENELEC safety standards and complies with European low-voltage directive. To Order a Coil choose Coil Ref + Voltage Code, example: 481865 for 24 VDC = 481865C2 More voltage possibilities can be found in the table of voltage codes at the end of the coil section. These coils must be used with suitable housings, see example below: The coil assembly kit Ref. 2995 corresponds to the "housing" of Lucifer® valve numbering system (Valve - housing - coil/voltage). It is composed of a nameplate giving details of the valve type, a round washer and a nut to ensure the fixing between 32 mm coil and the valve. 2.0/2.1 COIL GROUP Parker Hannifin Corporation Fluid Control Division Europe General Catalogue FCDE/0110/UK/V2.0 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Example: the valve 121K3206 is proposed with coil 481865 but is also compatible with the 2.0 coil group. This means the coil 482725 is also compatible with the chosen valve as it is within this group. When refering to the coil section you will find the coil group for each coil. This allows you to discover which other coils are compatible with the valve you have chosen. The coil section is at the end of the catalogue and displays the specifications of each coil, along with the reference number, class of insulation, ambient temperature, electrical power and weight. HOW TO USE COIL GROUPS WITHIN A COIL PAGE

Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 20 2 WAY VALVES NOTES

21 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Actuation Body Function Port Size Orifice (mm) Flow Factor Kv(l/min) MOPD (bar) Max Fluid Temp. (°C) Page Parker Valves Direct Operated Brass/Pipe Mounting Normally Closed 1/8" 1.5 to 3 4.5 70 130 22 1/4" 1.2 to 5 11 100 130 22 and 24 3/8" 4 to 6 12 10 120 26 1/2" 8.5 to 11 36 4 120 26 Normally Open 1/8" 2.5 3.5 30 140 28 1/4" 1.5 to 4.5 7.8 40 140 28 Control by Electric Impulse 1/4" 3 to 5 11 20 100 28 Brass/Sub-base Mounting Normally Closed 5 mm 1.5 to 3 4.5 100 130 30 Normally Open 5 mm 1.5 1.5 20 120 32 Magnalift Brass/Pipe Mounting Normally Closed 3/8" 15 65 20 140 34 1/2" 15 65 20 140 34 3/4" 15 80 20 140 36 1" 15 to 25 170 20 120 38 Pilot Operated Brass/Pipe Mounting Normally Closed 1/4" 8 to 12 36 40 120 40 3/8" 11 to 12 50 40 120 42 1/2" 11 to 15 60 40 120 44 3/4" 15 to 20 135 40 120 46 1" 18 to 25 185 16 120 48 1 1/4" 28 270 16 120 48 1 1/2" 40 425 16 120 50 2" 40 540 16 120 50 Normally Open 1/4" 8 36 40 140 52 3/8" 11 50 40 140 52 1/2" 15 60 40 140 52 3/4" 15 to 20 135 40 120 54 1" 25 180 16 120 54 1 1/4" 28 270 16 120 54 1 1/2" 40 420 12 100 54 2" 40 540 12 120 54 Control by Electric Impulse 1/4" 12 32 12 100 56 3/8" 12 45 12 100 56 1/2" 12 50 12 100 56 3/4" 18 100 12 100 56 1" 18 110 12 100 56 Brass/Sub-base Mounting Normally Closed 14 mm 14 45 40 140 58 Normally Open 14 mm 14 46 40 120 58 2 WAY VALVES VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 Oil Water Air

22 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED PIPE MOUNTING Port size (BSP) Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max mm Kv l/min KV m3/h Qn m3/h bar AC bar DC bar °C °C AC W DC W 1/8" 1.5 0.9 0.05 70 0 20 12 -10 75 FKM 121M14 8993 481180 4 5 1.1 3382 1.5 0.9 0.05 70 0 20 4 -10 75 FKM 121M14 8993 488980 2 2.5 1.1 3382 1.5 1.5 0.09 80 0 60 25 -30 75 PCTFE E121K14 2995 481865 8 9 2.0 3510 1.5 1.5 0.09 80 0 70 30 -30 75 PCTFE E121K14 4270 481000 8 8 2.0 3510 1.5 1.5 0.09 80 0 70 55 -30 75 PCTFE E121K14 4270 486265 14 14 2.0 3510 2 2 0.12 125 0 10 7 -10 75 FKM 121M13 8993 481180 4 5 1.1 3382 2 2 0.12 125 0 10 2.5 -10 75 FKM 121M13 8993 488980 2 2.5 1.1 3382 2.5 2.8 0.17 - 0 10 10 -10 75 FKM 121Z03 2995 481865 8 9 2.0 7863 2.5 3.5 0.21 220 0 28 10 -30 100 Ruby E121K23 2995 481865 8 9 2.0 3510 2.5 3.5 0.21 220 0 34 12 -30 130 Ruby E121K23 4270 481000 8 8 2.0 3510 2.5 3.5 0.21 220 0 50 22 -30 120 Ruby E121K23 4270 486265 14 14 2.0 3510 3 4.5 0.27 320 0 10 7 -10 100 FKM 121K1302 2995 481865 8 9 2.0 3510 3 4.5 0.27 320 0 10 8 -10 120 FKM 121K1302 4270 481000 8 8 2.0 3510 3 4.5 0.27 320 0 10 10 -10 120 FKM 121K1302 4270 486265 14 14 2.0 3510 1/4" 1.2 0.85 0.05 50 0 80 36 -30 100 Ruby E121K65 2995 481865 8 9 2.0 3510 1.2 0.85 0.05 50 0 100 43 -30 130 Ruby E121K65 4270 481000 8 8 2.0 3510 1.2 0.85 0.05 50 0 100 75 -30 120 Ruby E121K65 4270 486265 14 14 2.0 3510 1.5 1.5 0.09 80 0 - 8 -20 75 PUR 121K0497 1 2995 482740 - 1.6 6.0/8.0 8274 1.5 1.5 0.09 80 0 - 8 -20 65 PUR 121K0497 1 2995 496125 - 1.6 6.0/8.0 8274 1.5 1.5 0.09 80 0 10 10 -20 75 PUR 121K0497 1 - 495900 2.5 2 6.0/8.0 8274 1.5 1.5 0.09 80 0 - 10 -20 75 PUR 121K0497 1 - 495910 - 0.3- 1.2 6.0/8.0 8274 1.5 1.5 0.09 80 0 60 25 -30 75 PCTFE E121K04 2995 481865 8 9 2.0 3510 1.5 1.5 0.09 80 0 70 30 -30 75 PCTFE E121K04 4270 481000 8 8 2.0 3510 1.5 1.5 0.09 80 0 70 55 -30 75 PCTFE E121K04 4270 486265 14 14 2.0 3510 1.5 1.5 0.09 80 0 20 20 -10 100 FKM E121K0402 2995 481865 8 9 2.0/3.0 3510 1.5 1.5 0.09 80 0 20 20 -10 120 FKM E121K0402 4270 481000 8 8 2.0/3.0 3510 1.5 1.5 0.09 80 0 60 25 -30 100 Ruby E121K67 2995 481865 8 9 2.0 3510 1.5 1.5 0.09 80 0 75 30 -30 130 Ruby E121K67 4270 481000 8 8 2.0 3510 1.5 1.5 0.09 80 0 100 55 -30 120 Ruby E121K67 4270 486265 14 14 2.0 3510 2.5 3.5 0.21 220 0 14 7 -10 100 FKM 121K0706 2995 481865 8 9 2.0 3510 2.5 3.5 0.21 220 0 14 9 -10 120 FKM 121K0706 4270 481000 8 8 2.0 3510 2.5 3.5 0.21 220 0 14 14 -10 120 FKM 121K0706 4270 486265 14 14 2.0 3510 2.5 3.5 0.21 220 0 28 10 -30 75 PCTFE E121K07 2995 481865 8 9 2.0 3510 2.5 3.5 0.21 220 0 34 12 -30 75 PCTFE E121K07 4270 481000 8 8 2.0 3510 2.5 3.5 0.21 220 0 50 22 -30 75 PCTFE E121K07 4270 486265 14 14 2.0 3510 Notes: 1.If fluid is water, media temperature shall not exceed 40°C 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

23 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 7863 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 1/8" 1.2 0.9 2.5 -30 To 1/4" 3 4.5 100 130 2 WAY VALVES Drawing 3382 Drawing 3510

24 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED PIPE MOUNTING Port size (BSP) Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max mm Kv l/min KV m3/h Qn m3/h bar AC bar DC bar °C °C AC W DC W 1/4" 2.5 3.5 0.21 220 0 28 10 -30 100 Ruby E121K63 2995 481865 8 9 2.0 3510 2.5 3.5 0.21 220 0 34 12 -30 130 Ruby E121K63 4270 481000 8 8 2.0 3510 2.5 3.5 0.21 220 0 50 22 -30 120 Ruby E121K63 4270 486265 14 14 2.0 3510 3 3.5 0.21 250 0 - 2 -20 75 PUR 121K0397 1 2995 482740 - 1.6 6.0/8.0 8274 3 3.5 0.21 250 0 - 2 -20 65 PUR 121K0397 1 2995 496125 - 1.6 6.0/8.0 8274 3 3.5 0.21 250 0 4.5 4 -20 75 PUR 121K0397 1 - 495900 2.5 2 6.0/8.0 8274 3 3.5 0.21 250 0 - 4.5 -20 75 PUR 121K0397 1 - 495910 - 0.3- 1.2 6.0/8.0 8274 3 4.5 0.27 320 0 20 7 -30 75 PCTFE E121K03 2995 481865 8 9 2.0/3.0 3510 3 4.5 0.27 320 0 25 8.5 -30 75 PCTFE E121K03 4270 481000 8 8 2.0/3.0 3510 3 4.5 0.27 320 0 36 15 -30 75 PCTFE E121K03 4270 486265 14 14 2.0/3.0 3510 3 4.5 0.27 320 0 10 7 -10 100 FKM E121K0302 2995 481865 8 9 2.0 3510 3 4.5 0.27 320 0 10 8.5 -10 120 FKM E121K0302 4270 481000 8 8 2.0 3510 3 4.5 0.27 320 0 10 7 -10 100 FKM E121K0302 4270 486265 14 14 2.0 3510 3 4.5 0.27 320 0 10 7 -10 100 FKM E121K0352 2 2995 481865 8 9 2.0 3510 3 4.5 0.27 320 0 10 8.5 -10 120 FKM E121K0352 2 4270 481000 8 8 2.0 3510 3 4.5 0.27 320 0 10 10 -10 120 FKM E121K0352 2 4270 486265 14 14 2.0 3510 3 4.5 0.27 320 0 20 7 -30 100 Ruby E121K64 2995 481865 8 9 2.0 3510 3 4.5 0.27 320 0 25 8.5 -30 130 Ruby E121K64 4270 481000 8 8 2.0 3510 3 4.5 0.27 320 0 36 15 -30 120 Ruby E121K64 4270 486265 14 14 2.0 3510 4 7.5 0.45 480 0 10 4 -10 100 FKM 121K02 2995 481865 8 9 2.0 3510 4 7.5 0.45 480 0 10 5 -10 120 FKM 121K02 4270 481000 8 8 2.0 3510 4 7.5 0.45 480 0 10 10 -10 120 FKM 121K02 4270 486265 14 14 2.0 3510 4 7.5 0.45 480 0 10 4 -10 100 FKM 121K0250 2 2995 481865 8 9 2.0 3510 4 7.5 0.45 480 0 10 5 -10 120 FKM 121K0250 2 4270 481000 8 8 2.0 3510 4 7.5 0.45 480 0 10 10 -10 120 FKM 121K0250 2 4270 486265 14 14 2.0 3510 5 11 0.66 750 0 7 2 -10 100 FKM 121K01 2995 481865 8 9 2.0/14.2 3510 5 11 0.66 750 0 7 2.8 -10 120 FKM 121K01 4270 481000 8 8 2.0/14.2 3510 5 11 0.66 750 0 7 5 -10 120 FKM 121K01 4270 486265 14 14 2.0/14.2 3510 5 11 0.66 750 0 7 2 -10 100 FKM 121K0150 2 2995 481865 8 9 2.0 3510 5 11 0.66 750 0 7 2.8 -10 120 FKM 121K0150 2 4270 481000 8 8 2.0 3510 5 11 0.66 750 0 7 5 -10 120 FKM 121K0150 2 4270 486265 14 14 2.0 3510 6.5 - - 1400 0 0.5 0.5 -10 100 FKM 121K0601 2995 481865 8 9 2.0 3510 6.5 - - 1400 0 0.5 0.5 -10 120 FKM 121K0601 4270 481000 8 8 2.0 3510 Notes: 1.If fluid is water, media temperature shall not exceed 40°C 2.With manual override 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

25 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3510 Drawing 8274 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 1/4" 2.5 3.5 2 -30 To 1/4" 5 11 50 130 2 WAY VALVES

26 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED PIPE MOUNTING Port size (BSP) Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max mm Kv l/min KV m3/h Qn m3/h bar AC bar DC bar °C °C AC W DC W 3/8" 4 7.5 0.45 480 0 10 4 -10 100 FKM 121K3206 2995 481865 8 9 2.0 3551 4 7.5 0.45 480 0 10 5 -10 120 FKM 121K3206 4270 481000 8 8 2.0 3551 4 7.5 0.45 480 0 10 10 -10 120 FKM 121K3206 4270 486265 14 14 2.0 3551 5 11 0.66 750 0 7 2 -10 100 FKM 121K3106 2995 481865 8 9 2.0 3551 5 11 0.66 750 0 7 2.8 -10 120 FKM 121K3106 4270 481000 8 8 2.0 3551 5 11 0.66 750 0 7 5 -10 120 FKM 121K3106 4270 486265 14 14 2.0 3551 6 12 0.72 1100 0 5 1.1 -10 100 FKM 121K3306 2995 481865 8 9 2.0/14.2 3551 6 12 0.72 1100 0 5 1.5 -10 120 FKM 121K3306 4270 481000 8 8 2.0/14.2 3551 6 12 0.72 1100 0 5 3 -10 120 FKM 121K3306 4270 486265 14 14 2.0/14.2 3551 1/2" 8.5 25 1.5 1600 0 1.1 0.5 -10 100 FKM E121K46 2995 481865 8 9 2.0 3427 8.5 25 1.5 1600 0 2.2 0.5 -10 120 FKM E121K46 4270 481000 8 8 2.0 3427 8.5 25 1.5 1600 0 4 1.2 -10 120 FKM E121K46 4270 486265 14 14 2.0 3427 11 36 2.16 2500 0 0.7 0.3 -10 100 FKM E121K45 2995 481865 8 9 2.0 3427 11 36 2.16 2500 0 1.2 0.35 -10 120 FKM E121K45 4270 481000 8 8 2.0 3427 11 36 2.16 2500 0 2.5 0.7 -10 120 FKM E121K45 4270 486265 14 14 2.0 3427 2 WAY VALVES VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2 DIRECT OPERATED

27 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3551 Drawing 3427 2 WAY VALVES For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 3/8" 4 7.5 0.3 -10 To 1/2" 11 36 10 120

28 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY OPEN PIPE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 1/8" 2.5 3.5 0.21 - 0 30 - -30 140 Ruby 122K9363 4270 481044 14 - 2.2 3510 2.5 3.5 0.21 - 0 30 30 -30 140 Ruby 122K9363 4270 486265 14 14 2.2 3510 1/4" 1.5 1.5 0.09 80 0 30 30 -10 100 PCTFE 122K84 2995 481865 8 9 2.0 3510 1.5 1.5 0.09 80 0 30 30 -10 100 PCTFE 122K84 4270 481000 8 8 2.0 3510 1.5 1.5 0.09 80 0 30 30 -10 120 PCTFE 122K84 4270 486265 14 14 2.0 3510 1.5 1.5 0.09 80 0 20 20 -10 100 FKM 122K8406 2995 481865 8 9 2.1 3510 1.5 1.5 0.09 80 0 20 20 -10 120 FKM 122K8406 4270 481000 8 8 2.1 3510 1.5 1.5 0.09 80 0 40 40 -30 100 Ruby 122K8408 2995 481865 8 9 2.0 3510 1.5 1.5 0.09 80 0 40 40 -30 130 Ruby 122K8408 4270 481000 8 8 2.0 3510 1.5 1.5 0.09 80 0 40 40 -30 130 Ruby 122K8408 4270 486265 14 14 2.0 3510 2.5 3 0.18 180 0 12 12 -30 75 PCTFE 122K83 2995 481865 8 9 2.0 3510 2.5 3 0.18 180 0 12 12 -30 75 PCTFE 122K83 4270 481000 8 8 2.0 3510 2.5 3 0.18 180 0 12 12 -30 75 PCTFE 122K83 4270 486265 14 14 2.0 3510 2.5 3 0.18 180 0 12 12 -10 100 FKM 122K8306 2995 481865 8 9 2.0 3510 2.5 3 0.18 180 0 12 12 -10 120 FKM 122K8306 4270 481000 8 8 2.0 3510 2.5 3 0.18 180 0 12 12 -10 120 FKM 122K8306 4270 486265 14 14 2.0 3510 2.5 3.5 0.21 - 0 30 - -30 140 Ruby 122K8363 4270 481044 14 - 2.2 3510 2.5 3.5 0.21 - 0 30 30 -30 140 Ruby 122K8363 4270 486265 14 14 2.2 3510 4.5 7.8 0.47 - 0 4 4 -10 120 FKM 122K8606 1 2995 492425 14 14 - 3510 Notes: BRASS CONTROL BY ELECTRIC IMPULSE PIPE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 1/4" 3 4.5 0.27 320 0 20 - -30 75 PCTFE 125K03 4269 484990 11 - 4.0 8296 3 4.5 0.27 320 0 - 7 -30 75 PCTFE 125K03 4269 485400 - 13 4.0 8296 5 11 0.66 750 0 5 - -10 100 FKM 125K01 4269 484990 11 - 4.0 8296 5 11 0.66 750 0 - 1.5 -10 100 FKM 125K01 4269 485400 - 13 4.0 8296 1. Valve compatible only with 492425 or 491514 coils 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

29 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3510 Drawing 8296 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 1/8" 1.5 1.5 1.5 -30 To 1/4" 5 11 40 140 2 WAY VALVES

30 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED SUB-BASE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W SB 1.5 1.5 0.09 80 0 20 - -10 100 EPDM 121F4417 2995 483510 9 - 2.0 3509 1.5 1.5 0.09 80 0 60 25 -30 100 Ruby 121F67 2995 481865 8 9 2.0 3509 1.5 1.5 0.09 80 0 75 30 -30 130 Ruby 121F67 4270 481000 8 8 2.0 3509 1.5 1.5 0.09 80 0 100 55 -30 120 Ruby 121F67 4270 486265 14 14 2.0 3509 1.5 1.5 0.09 80 0 60 25 -30 75 PCTFE E121F44 2995 481865 8 9 2.0 3509 1.5 1.5 0.09 80 0 70 30 -30 75 PCTFE E121F44 4270 481000 8 8 2.0 3509 1.5 1.5 0.09 80 0 70 55 -30 75 PCTFE E121F44 4270 486265 14 14 2.0 3509 1.5 1.5 0.09 80 0 20 20 -10 100 FKM E121F4406 2995 481865 8 9 2.0 3509 1.5 1.5 0.09 80 0 20 20 -10 120 FKM E121F4406 4270 481000 8 8 2.0 3509 1.5 1.5 0.09 80 0 20 20 -10 120 FKM E121F4406 4270 486265 14 14 2.0 3509 2.5 3.5 0.21 220 0 28 10 -30 75 PCTFE 121F47 2995 481865 8 9 2.0 3509 2.5 3.5 0.21 220 0 34 12 -30 75 PCTFE 121F47 4270 481000 8 8 2.0 3509 2.5 3.5 0.21 220 0 50 22 -30 75 PCTFE 121F47 4270 486265 14 14 2.0 3509 2.5 3.5 0.21 220 0 14 7 -10 100 FKM 121F4706 2995 481865 8 9 2.0 3509 2.5 3.5 0.21 220 0 14 9 -10 120 FKM 121F4706 4270 481000 8 8 2.0 3509 2.5 3.5 0.21 220 0 14 14 -10 120 FKM 121F4706 4270 486265 14 14 2.0 3509 2.5 3.5 0.21 220 0 28 10 -30 100 Ruby 121F63 2995 481865 8 9 2.0 3509 2.5 3.5 0.21 220 0 34 12 -30 130 Ruby 121F63 4270 481000 8 8 2.0 3509 2.5 3.5 0.21 220 0 50 22 -30 120 Ruby 121F63 4270 486265 14 14 2.0 3509 3 4.5 0.27 320 0 20 7 -30 100 Ruby 121F64 2995 481865 8 9 2.0 3509 3 4.5 0.27 320 0 25 8.5 -30 130 Ruby 121F64 4270 481000 8 8 2.0 3509 3 4.5 0.27 320 0 36 15 -30 120 Ruby 121F64 4270 486265 14 14 2.0 3509 3 4.5 0.27 320 0 20 7 -30 75 PCTFE E121F43 2995 481865 8 9 2.0 3509 3 4.5 0.27 320 0 25 8.5 -30 75 PCTFE E121F43 4270 481000 8 8 2.0 3509 3 4.5 0.27 320 0 36 15 -30 75 PCTFE E121F43 4270 486265 14 14 2.0 3509 3 4.5 0.27 320 0 10 7 -10 100 FKM E121F4302 2995 481865 8 9 2.0/3.0 3509 3 4.5 0.27 320 0 10 8.5 -10 120 FKM E121F4302 4270 481000 8 8 2.0/3.0 3509 3 4.5 0.27 320 0 10 10 -10 120 FKM E121F4302 4270 486265 14 14 2.0/3.0 3509 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

31 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3509 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 5 mm 1.5 1.5 7 -30 To 5 mm 3 4.5 100 130 2 WAY VALVES

32 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY OPEN SUB-BASE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W SB 1.5 1.5 0.09 80 0 20 20 -10 100 FKM 122F44 2995 481865 8 9 2.1 3509 1.5 1.5 0.09 80 0 20 20 -10 120 FKM 122F44 4270 481000 8 8 2.1 3509 2 WAY VALVES DIRECT OPERATED VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

33 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3509 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 5 mm 1.5 1.5 20 -10 To 5 mm 1.5 1.5 20 120 2 WAY VALVES

34 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED PIPE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 3/8" 15 65 3.9 4500 0 16 - -10 100 NBR 221G13 2995 481865 8 - 2.0 3732 15 65 3.9 4500 0 16 - -10 100 NBR 221G13 4270 481000 8 - 2.0 3732 15 65 3.9 4500 0 16 16 -10 100 NBR 221G13 4270 486265 14 14 2.0 3732 15 65 3.9 4500 0 16 - 0 100 FKM 221G23 1 2995 481865 8 - 2.0 3732 15 65 3.9 4500 0 16 - 0 120 FKM 221G23 1 4270 481000 8 - 2.0 3732 15 65 3.9 4500 0 20 7 0 140 FKM 221G23 1 4270 486265 14 14 2.0 3732 15 65 3.9 4500 0 - 10 -10 100 FKM 221G2330 12 2995 481865 - 9 2.1 3732 15 65 3.9 4500 0 10 10 -10 65 FKM 221G2330 12 - 492070 9 8 2.1 3732 15 65 3.9 4500 0 10 10 -10 75 FKM 221G2330 12 - 492190 11 9 2.1 3732 1/2" 15 65 3.9 4500 0 16 - -10 100 NBR 221G15 2995 481865 8 - 2.0 3732 15 65 3.9 4500 0 16 - -10 100 NBR 221G15 4270 481000 8 - 2.0 3732 15 65 3.9 4500 0 16 7 -10 100 NBR 221G15 4270 486265 14 14 2.0 3732 15 65 3.9 4500 0 - 10 -10 100 NBR 221G1530 23 2995 481865 - 9 2.1 3732 15 65 3.9 4500 0 10 10 -10 65 NBR 221G1530 23 - 492070 9 8 2.1 3732 15 65 3.9 4500 0 10 10 -10 75 NBR 221G1530 23 - 492190 11 9 2.1 3732 15 65 3.9 4500 0 16 - 0 100 FKM 221G25 1 2995 481865 8 - 2.0 3732 15 65 3.9 4500 0 16 - 0 120 FKM 221G25 1 4270 481000 8 - 2.0 3732 15 65 3.9 4500 0 20 7 0 140 FKM 221G25 1 4270 486265 14 14 2.0 3732 15 65 3.9 4500 0 - 10 -10 100 FKM 221G2530 12 2995 481865 - 9 2.1 3732 15 65 3.9 4500 0 10 10 -10 65 FKM 221G2530 12 - 492070 9 8 2.1 3732 15 65 3.9 4500 0 10 10 -10 75 FKM 221G2530 12 - 492190 11 9 2.1 3732 Notes: 1.Valve only compatible with hydraulic oil and air/neutral gases 2.Valves with model number ending in 30 or 31 are mainly equipped with electrical parts for explosion proof applications or with standard DC coils. 3. With 4 position selector for controlled closure rate. 4.Pilot seat in FKM 2 WAY VALVES MAGNALIFT VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2

35 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 Drawing 3732 For this page Port size Orifice (mm) Kv (l/min) MOPD (bar) Fluid Temp (°C) From 3/8" 15 65 7 -10 To 1/2" 15 65 20 140 2 WAY VALVES

36 Parker Hannifin Corporation Fluid Control Solutions Europe General Catalogue FCSE/0112/UK V2.2 07/2022 BRASS NORMALLY CLOSED PIPE MOUNTING Port size Orifice Ø Flow factors Operating Pressure Differential Fluid Temp. Seat Seal Power Coil Group Dwg. No. Valve Ref. Housing Ref. Coil Ref. Min Max(MOPD) Min Max BSP mm Kv l/min KV m3/h Qn l/min bar AC bar DC bar °C °C AC W DC W 3/4" 15 80 4.8 6000 0 16 - -10 100 NBR 221G16 4 2995 481865 8 - 2.0 3444 15 80 4.8 6000 0 16 - -10 100 NBR 221G16 4 4270 481000 8 - 2.0 3444 15 80 4.8 6000 0 7 7 -10 100 NBR 221G16 4 4270 486265 14 14 2.0 3444 15 80 4.8 6000 0 16 - -10 100 NBR 221G1610 3 2995 481865 8 - 2.0 3444 15 80 4.8 6000 0 16 - -10 100 NBR 221G1610 3 4270 481000 8 - 2.0 3444 15 80 4.8 6000 0 16 7 -10 100 NBR 221G1610 3 4270 486265 14 14 2.0 3444 15 80 4.8 6000 0 10 10 -10 100 NBR 221G1630 24 2995 481865 8 9 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 NBR 221G1630 24 - 492070 9 8 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 NBR 221G1630 24 - 492190 11 9 2.1 3444 15 80 4.8 6000 0 10 10 -10 100 NBR 221G1631 234 2995 481865 8 9 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 NBR 221G1631 234 - 492070 9 8 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 NBR 221G1631 234 - 492190 11 9 2.1 3444 15 80 4.8 6000 0 16 - 0 100 FKM 221G26 1 2995 481865 8 - 2.0 3444 15 80 4.8 6000 0 16 - 0 120 FKM 221G26 1 4270 481000 8 - 2.0 3444 15 80 4.8 6000 0 20 7 0 140 FKM 221G26 1 4270 486265 14 14 2.0 3444 15 80 4.8 6000 0 - 10 -10 100 FKM 221G2630 12 2995 481865 - 9 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 FKM 221G2630 12 - 492070 9 8 2.1 3444 15 80 4.8 6000 0 10 10 -25 40 FKM 221G2630 12 - 492190 11 9 2.1 3444 Notes: 1.Valve only compatible with hydraulic oil and air/neutral gases 2.Valves with model number ending in 30 or 31 are mainly equipped with electrical parts for explosion proof applications or with standard DC coils. 3. With 4 position selector for controlled closure rate. 4.Pilot seat in FKM 2 WAY VALVES MAGNALIFT VALVES FOR DRY OR LUBRICATED AIR, NEUTRAL GASES AND LIQUIDS 2/2
